A-rack AP3000 Metered & Switched PDU

AP3002-2004
Enquiry
RakworX Switched Rack Power Distribution Units (PDUs) enable advanced, user-customizable power control and active monitoring. Remote outlet level controls allow power on/off functionality for power cycling to remotely reboot equipment and restrict unauthorized use of individual outlets. Power sequencing time delays allow users to define the order in which to power up or down attached equipment to avoid circuit overload. Current metering provides real-time remote monitoring of connected loads with user-defined alarms to warn of potential circuit overloads. Users can access, configure, and control Switched Rack PDUs through MODBUS which are complimented by RakworX Centralized Management platforms using Data Center Expert, Operations, Capacity, and Energy Efficiency. AP3000 series Switched Rack PDUs include real power monitoring, a temperature/humidity sensor port, and locking IEC receptacles.
view product overview
  • Product Description
  • Technical Specifications
  • Download
Product Description

AP3000 Series Switched Rack Power Distribution Units (PDUs) provide advanced load monitoring combined with remote on/off switching control of individual outlets for power cycling, delayed power sequencing, and outlet use management.

IEC60950 industrial  standard PDU

Multiple locking IEC socket

Socket color management

Compact size, only 50mm

Optional sensor, rich  function expansion

Remote switch each port

Accurate measurement of  embedded operating  system, intelligent control.

Work with centralized  control platform perfectly compatible

Technical Specifications
Output
Nominal output voltage
200-240V
Maximum total current draw
24A
Output connections
IEC C13[20]+C19[4]
Input
Nominal input voltage
200-208V
Input frequency
50/60 Hz
Input connections
IEC309 or NEMA plug
Cord length
3M
Number of power cords
1
Maximum input current
24A
Environmental
Operating environment
0-45°C
Operating relative humidity
0-95%
Storage relative humidity
0-95%
Operating elevation
0-3000 meters
Storage temperature
-25-65°C
Storage elevation
0-15000 meters
Physical
Maximum height
50mm
Maximum width
55mm
Maximum depth
1785mm
Net weight
7.5KGS
Color
black
Sustainable Offer Status
RoHS
Compliant
CE
Compliant
SGS
Available in download
Download
AP3002-2004 Drawing 524KB113
